在高楼林立的当代城市中，垂直的空间亦须要方案出一片绿洲。
我希望建筑能够摆脱那些伟大的意义变得更加轻盈和放松，让阳光和鸟儿可以穿越而过，让市民能够随意的爬到百米高的楼上遛弯儿。

深圳重塑建筑设计常见问题

项目背景

Background

园地现状

随着城市人口对付身心康健意识的觉醒，在寸土寸金的深圳文体中央正快速向着更高、更密、功能更加稠浊的方向发展。
本项目位于龙城街道快意路与龙岗大道交叉口东南方向，占地面积 7434.3㎡，总建筑面积 48596 ㎡，建筑限高90m，须要同时容纳 16659㎡文化中央、10100㎡体育中央、5700㎡商业配套举动步伐。
基于园地和项目的情形，须要办理以下几个问题：如何在狭小的园地上培植一个功能繁芜的公共建筑，让文化、体育、商业功能相互独立又相互联系？如何让一个90m的高层建筑仍旧具备良好的公共性和可达性？如何弱化一个尺度弘大的建筑，让他可以与城市、与自然和谐相处？

With the awakening of urban population's awareness of physical and mental health, Shenzhen's cultural and sports center is rapidly developing in the direction of higher, denser, and more mixed functions. This project is located in the southeast of the intersection of Ruyi Road and Longgang Avenue in Longcheng Street. It covers an area of 7434.3㎡, with a total construction area of 48596㎡, and a building height limit of 90m. It needs to accommodate 16659㎡ cultural center, 10100㎡ sports center and 5700㎡ commercial facilities at the same time. facility. Based on the situation of the site and the project, the following issues need to be solved: How to build a public building with complex functions on a small site so that cultural, sports, and commercial functions are independent and interconnected? How to make a 90m high-rise building still have good publicity and accessibility? How to weaken a large-scale building so that it can live in harmony with the city and nature?

设计意向

Design intent

堆砌的石块

堆砌的行为授予石块分外意义，犹如西西弗神话抑或是玛尼堆。

The act of piling gives special meaning to the stones, such as the stone of the ''Le Mythe de Sisyphe''or ''Dobeng''Stone in Tibet.

叠石

Stacked

狭小的园地和高容积率匆匆使了建筑以塔楼的办法布局，通过把文化类和体育类分别置于两个独立的塔楼可以很好的办理文体之间动静分区的问题。
剧院、青少年活动中央、商业配套、门球馆这些须要独立对外的功能置于地面层附近，图书室和书吧这类须要良好景不雅观和安静氛围的功能置于高区。

The narrow space and high plot ratio promote the layout of buildings in the form of towers. By placing culture and sports in two independent towers, the problem of dynamic and static division between styles can be solved. Theaters, youth activity centers, commercial facilities and gatehouses are located near the ground floor, while libraries and Book bars, which need good landscape and quiet atmosphere, are located in high-rise areas.

通过裙房与屋顶的链接，让双塔进化成了一个立体的环状交通，既知足了动静分区，又平衡了文体之间功能的连通问题。
通过不同功能彼此错动独立成块，既让弘大的建筑尺度得以降解，又产生了空中景不雅观露台。
如同一个个大小不一的巨石垒在一起，有机的堆叠成了一座环形雕塑。

Through the link between the podium and the roof, the twin towers have evolved into a three-dimensional circular traffic, which not only meets the dynamic and static zoning, but also balances the functional connectivity between styles.Through the different functions of each other staggered independent block, not only let the huge building scale degradation, but also produced the air landscape terrace. Like a different size of boulders together, organic stacked into a ring sculpture.

城市中的人们在高楼大厦间穿行来到这里，轻盈的银白色表皮和交错的体块首先映入眼帘，缝隙之间透出的绿色又让它轻微显得有一点神秘，银色波纹金属网表皮后若隐若现的V字型构造授予文体中央独特的美感。
逐步靠近，丛林般的中庭呈现在人们的面前，在立体的空间中宛如一个沙漠中的绿洲，改变人们对传统城市天涯线的印象。

People in the city shuttled between the tall buildings and came here. The faint silver-white skin and interlaced clumps first came into view, and the green radiating from the gap made it a little mysterious. The looming V-shaped structure behind the silver corrugated metal mesh gives a unique beauty to the style and sports center. Slowly approaching, the jungle-like atrium appeared in front of everyone. This space is like an oasis in the desert, to change people's impression of the traditional urban skyline.

峡谷

Gorge

由文化、体育、商业功能混和而成的这座充满能量的环形建筑，不但为城市注入了新的活力，还以其独特的形态成为了城市街道的标志性景不雅观节点。
由环形体块围合而成的这个60m净空的开放中庭，是一个让文化、体育与城市生活交汇的城市客厅。
中央露台为集会、路演、街舞、演奏、展览、秀场、露天电影等活动创造了一个半户外的园地，以开放原谅的姿态欢迎龙岗市民。

This energetic circular building, which is composed of culture, sports and commercial functions, not only injects new vitality into the city, but also becomes the landmark landscape node of the city streets with its unique form.The 60m open atrium enclosed by a circular block is an urban living room where culture, sports and urban life meet. The central terrace creates a semi outdoor venue for assembly, roadshow, hip-hop dance, performance, exhibition, show, open-air film and other activities to welcome Longgang citizens with an open and inclusive attitude.

连接爱联站和龙岗河的二层连桥系统，与文体中央内庭的立体交通连通，创造了一条24小时无条件向市民开放的公共休闲登高环路。
环路顶部串联的空中不雅观景平台和云端书吧，将成为路子龙城街道必达的旅游不雅观光打卡点。

The two-story bridge connecting Ailian station and Longgang River, connected with the three-dimensional traffic in the inner court of the sports center, creates a 24-hour public leisure and climbing ring road which is open to the public unconditionally. The air viewing platform and cloud book bar connected at the top of the ring road will become a tourist card punch point which must be reached by Longcheng street.

建筑内庭不同标高的栽种池把自然从地面带上了高空，满布的藤曼和灌木让建筑成为了一个绿意盎然的立体城市花园。

The planting pool with different elevation in the inner chamber brought nature from the ground to the high altitude. The full of vines and shrubs made the building a green three-dimensional urban garden.

置身于峡谷之中在中庭的底部举头望去，波光粼粼的镜面金属板像是万花筒般将峡谷的景致重组呈现，天空和峡谷仿佛领悟相接。
轻盈通透的钢索玻璃吊桥和镜面顶部将人们在中庭体验推向高潮。

Standing in the gorge and looking up at the bottom of the atrium, the shimmering mirror resembles a kaleidoscope reorganizing the scenery of the gorge, and the sky and the gorge seem to merge and connect. The light and transparent bridge and the mirror top push people to experience the climax in the atrium.

体育中央

Sports center

巨型桁架支撑起文体中央的大跨度空间，光芒通过银色波纹金属网表皮柔和的照进室内，留下树荫一样平常的痕迹。

The giant truss supports the large-span space in the center of the style and sports center, and the light enters the room softly through the silver corrugated metal mesh, leaving traces of shade.

露台花园

Sky garden

热带植物搭配的露台像是一个个小公园，走出室内看看远处的城市，面对植物安歇少焉。
建筑的中庭和外侧，大大小小栽种区分布在各个角落和平台，爬藤、灌木、小乔木在立体空间中交错相映。
屋面露台层层向东西两侧伸展，让人们可以远眺马鞍岭和大运中央。

Terrace with tropical plants like a small forest, people can get out of the room and see the distant city, facing plant break. In every corner of the building, planting areas are distributed in all corners and platforms, vine and trees are interlaced in the space. The roof terrace extends from layer to layer to East and West, so that people can overlook Ma'anling and Universiade center.

观点剖析图

Concept

可旁边滑动

剖析图

剖面大样

剖面图

技能图纸

Drawing

可旁边滑动

平面图

立面图

功能流线
